AIM- Air Impulse Mouldmaster

The AIM is a German proven technology having a

horizontal flask turn-style moulding machine, designed for foundries wanting a flexible solution for production of high quality, medium and heavy near net shape castings

The rigidity of the machine with air impulse technology ensures high quality casting finish. The machine is designed to ensure uniform mould compaction throughout the mould.

We provide the standalone equipment as well as along with the entire line.

Flask Size- 300x450mm upto 1000x1200mm

With more than 3 decades of experience in building and

manufacturing the most dependable foundry equipment running across

the country.

The DARPA series provides the sturdiest design and serves as the

benchmark for simultaneous jolt squeeze moulding machine.

The high frequency, low amplitude jolting with high dynamic squeeze

force for uniform and rigid moulds is engineered for easy maintenance.

All parts accessible above floor level for easy maintenance.

Completely pneumatically operated with better productivity time.

Our Product line- DARPA 300, 450,700, 900 and 1300

Flask Size- 300x300 upto 1200x1000

Our biggest high pressure moulding machine specially designed to handle, manage

and produce large castings with sizes extending upto 3.6mt x 2 mt x 500 mm (H) with a 12 MT with hydraulic squeeze.

The equipment along with its arrangements for pattern shuttling systems, pattern strip off, sand leveling, sand filling and core-box setting stations is a complete mould handling line.

Managing a mould hardness of 90BHN vertical and 95 BHN horizontal. The Goliath is designed for manufacturers using green sand to make large castings.

Its unique design helps the equipment run on a very cost-effective running cost.

Specially designed for Railway Bogeys, Large size pumps.

Do reach out with your sizes and we shall provide you the best possible solution.

Flask size- 1500x1500 upto 3000x1500x500(H)mm

The DT range of machines are a swing head style design that utilizes both a low frequency, long stroke anvil jolt for pre-compaction of the molds well as simultaneous jolt squeeze for the final compaction.

The equipment does not require a foundation pit and is placed on ground level for effective use and maintenance of equipment.

Its simplicity of design offers to be used as a standalone equipment which can be supplemented with a pattern shuttle system for moulding.

Its unique design often serves effective with large size castings with shallow pattern depths.

Flask size- 500x500 upto 1300x1200mm
